FIM7L ATG Console
Automation Systems / Tank Gauging Console (ATG Console)
Description
FIM7L ATG Console
Smart Interaction, Limitless Performance, Total Control
The FIM7L ATG Console is a next-generation automatic tank monitoring and management platform developed for modern fuel stations, storage terminals, and industrial fuel infrastructures. Engineered by FIMTEK and combined with General Petrol’s field experience and system integration expertise, the FIM7L delivers superior control, safety, and operational efficiency in tank and pump management.
The FIM7L is not merely a display unit; it is an advanced ATG (Automatic Tank Gauging) console that acts as the central intelligence hub, seamlessly connecting tanks, pumps, sensors, and automation systems.
Centralized and Real-Time Tank Management
The FIM7L ATG Console continuously monitors critical parameters such as tank levels, volumes, temperature, water level, product type, and density, presenting real-time data to operators via a high-resolution touchscreen interface.
The system is capable of managing:
Up to 64 tanks
Up to 16 pumps
simultaneously. Tanks can be monitored independently, in groups, or in manifold configurations, making the FIM7L an ideal solution for large-scale facilities and multi-site fuel networks.
Advanced User Interface and Operator Experience
The 7-inch high-resolution touchscreen, combined with fast navigation and an intuitive interface design, allows operators to access all critical information at a glance.
Key displayed data includes:
Tank level and volume information
Water level and alarm status
Product temperature
Filling and overfill conditions
Active alarms and system warnings
The graphical display structure enables even complex site operations to be managed easily and efficiently.
Intelligent Alarm, Overfill, and Leak Management
The FIM7L provides 24/7 operational protection through automatic filling detection, overfill prevention, and advanced alarm algorithms. The system supports:
Instant overfill alarms
Level-based threshold alerts
Integrated or external leak detection systems
Calendar-based alarm, delivery, and warning filtering
All events are time-stamped, logged, and stored for traceability and historical analysis.
Wide Sensor Compatibility and Measurement Flexibility
The FIM7L ATG Console is compatible with a wide range of sensors, including:
Magnetostrictive level probes
Temperature sensors
Water detection sensors
Different probe technologies can operate simultaneously within the same system architecture.
The console automatically performs:
Temperature-compensated volume calculations (TC volume)
Corrected density calculations
ensuring maximum inventory accuracy and measurement reliability.
Powerful Communication and Integration Infrastructure
The FIM7L is designed to operate seamlessly with both modern and legacy systems. Supported communication interfaces include:
Ethernet
4G GSM
USB
HDMI
Multiple RS ports
With support for industry-standard protocols such as Modbus RTU/TCP, the system integrates smoothly with:
POS systems
SCADA and automation platforms
Remote monitoring and management systems
General Petrol designs and implements these integrations on a project basis, delivering end-to-end solutions from field hardware to software layers.
Local and Remote Monitoring – Cloud-Enabled Architecture
The FIM7L supports both local and remote monitoring for single sites as well as multi-station networks. Through its web-based interface, the system can be accessed via PC, tablet, or mobile devices.
Additional capabilities include:
Email notifications (alarms, deliveries, shift reports)
Cloud-based data backup
Remote firmware updates
Configuration import and export
Reporting, Data Logging, and Operational Analysis
The system provides printer support for inventory, delivery, leak test, reconciliation, and shift reports. Long-term data logging enables:
Historical analysis
Audit and compliance processes
Operational performance evaluation
to be carried out efficiently and reliably.
Modular, Scalable, and Future-Ready Design
The FIM7L ATG Console features:
Modular I/O architecture
Expandable relays, inputs, and communication channels
Compatibility with future sensors and communication standards
Its scalable design protects investment value and allows the system to grow in line with operational needs.
Safe Operation in Hazardous Areas
With an optional Ex-proof external enclosure, the FIM7L can be safely deployed in hazardous environments. The system is designed in compliance with ATEX and CE requirements.
The General Petrol & FIMTEK Integrated Solution
The FIM7L ATG Console is developed with FIMTEK’s software and electronics expertise and integrated into projects with General Petrol’s field experience, engineering approach, and after-sales assurance.
This integrated structure provides customers with:
The advantages of local technology and manufacturing
Rapid technical support
Project-specific system configuration
Long-term service continuity
